High Quality Led Tunnel Light for Project AGTL01

Strong Heat Dissipation
High Efficiency 130-1 50lm/W
Integrated Tempered Glass
Uniform Light Output
Lamp length can be customized
LED Brand: Lumileds/Osram/Nichia/Cree
Driver: Meanwell/Inventronics/Philips/Moso/Sosen….
Dimming: 0-10V /DALI /PWM / TIMMING  for optional
IP rate: IP65
IK rate: IK08
MOQ: 1 PC
Warranty: 50,000hrs/5 Years
Certificate: CE ROHS  ISO9001 ISO14001
Availability:


MODEL AGTL0101
Power 20-80W
LED Lumileds/Osram/Nichia/Cree
Lumen Efficiency 130-150 lm/W
CCT 4000K/5000K
CRI Ra≥70
Beam Angle 105°
Driver Inventronics/Meanwell/Osram/Philips/Sosen
Input Voltage 100-277 VAC (180-528 VAC optional ), 50/60Hz
PF ≥0.9
Dimming 0-10V/PWM/Timmer Dimming/DALI Optional
IP Grade IP65
IK Grade IK08
Working Temp -20℃ ~ 50℃
Certificate CE/RoHS/ISO9001/ISO14001
Warranty 5 years
Options SPD/Long cable/Single  controller
Supported Files LM79/LM80/TM21/IES File/DiaLux Simulation/Salt Spray Test Report/Vibration Test Report etc.


AGTL01 LED Tunel Light Spec_01
