| MODEL | AGSS0601 | AGSS0602 | AGSS0603 |
| Power | 30W | 40W | 50W |
| LED | Lumileds/Osram/Nichia/Cree | ||
| Lumen Efficiency | 100 lm/W | ||
| CCT | 5000K/4000K | ||
| CRI | Ra≥70 (Ra>80 optional) | ||
| Beam Angle | Type II | ||
| System Voltage | DC 12.8V | ||
| Battery Parameters | 18AH | 24AH | 30AH |
| Solar Panel | 18V 40W | 18V 50W | 18V 70W |
| IP Grade | IP65 | ||
| IK Grade | IK08 | ||
| Working Temp | -10℃ -50℃ | ||
| Warranty | 3 Years | ||
| Charge Time | 6hours (Effective daylight) | ||
| Working Time | 2~4 days( Auto control by sensor) | ||
| Supported Files | LM79/LM80/TM21/IES File/DiaLux Simulation/Salt Spray Test Report/Vibration Test Report etc. | ||
